30 ton 4-post benchtop bulge forming press to accommodate existing tooling
Tonnage30
ApplicationBulge Forming
IndustrySafety
Frame Style4-Post, Benchtop
Special Features• Cylinder rod machined to accommodate existing tooling
• TEFC motor mounted oil cooler
Intended UseUsed to bulge form rupture discs for high-pressure systems

Custom Features:

  • Punching capacity: 5 Tons; Stripping capacity: 5 Tons
  • 5” Bore, 2 ½” Rod Parker hydraulic cylinder as main ram equipped with an anti-rotation device
  • Skid mounted power system and reservoir
  • Kidney loop filter/cooler circuit with TEFC motor mounted oil cooler
  • Calculated Ram Speeds: Pressing: 0-23 IPM; Return: 0-31 IPM
  • Two hand operation with feather touch hand lever and safety palm button providing infinitely variable speed
  • Dwell capability

Learn more about Bulge Forming, 4-Post/4-Column Presses, and Benchtop Presses in our Hydraulic Press Handbook.

Common Features on Beckwood Presses:

  • Heavy duty box beam design for superior rigidity and modular tie rod assembly utilizing pre-tensioning nuts for optimum performance
  • Fully adjustable Parker cylinders with full rated tonnage throughout the stroke
  • PressLink Remote Support module for complementary diagnostics & troubleshooting
  • Dual linear and pressure transducers in the main ram cylinders for optimal reliability and redundancy
  • Allen Bradley or Siemens PLC, programmable control system with touch screen HMI and Recipe Functionality
  • Structure designed for Infinite Life in accordance with rigorous simulation analysis through FEA (Finite Element Analysis) design testing
  • Backed by Beckwood’s industry leading dedicated service and support team
